Q. Write notes on clamping ?
When a signal drives an open-ended capacitor the average voltage level on the output terminal of the capacitor is determined by the initial charge on that terminal and may therefore be quite unpredictable. Thus it is necessary to connect the output to ground or some other reference voltage via a large resistor. This action drains any excess charge and results in an average or DC output voltage of zero.
A simple alternative method of establishing a DC reference for the output voltage is by using a diode clamp as shown in figure . By conducting whenever the voltage at the output terminal of the capacitor goes negative, this circuit builds up an average charge on the terminal that is sufficient to prevent the output from ever going negative. Positive charge on this terminal is effectively trapped.
Q. Explain Block diagram of the system? The block diagram is a pictorial representation of the equations of the system. Each block represents a mathematical operation, and the
DESIGN A MOD-6 ASYNCHRONOUS COUNTER
diagram of armeture reaction
Q. Consider the circuit shown in Figure. (a) Given v(t) = 10e -t V, find the current source is(t) needed. (b) Given i(t) = 10e -t A, find the voltage source v (t) needed.
circuit used in window air conditioning
FIGURE shows a pneumatic circuit diagram used for air supply and exhaust in an automatic control system. (a) Name all symbols (including pipelines) used in the system. (b) N
An automotive manufacturing company is planning to bring out a new model of a compact car for the Indian market. One of the critical tasks is choosing an engine with a proper engin
Q. Write down Shockley's equation. What is its importance? I D = I DSS [1-(V GS /V P )]^2 Shockley's equation is used to plot transfer characteristics. The transfer charac
1. The circuit shown below is a DC charging and discharging circuit. a. At t = 0 sec, switch S1 is thrown to position 1 ("pos1"). Write the mathematical expressions for V
Q. Consider the circuit of Figure. Determine and sketch i L (t) and v C (t) for capacitance values of (a) 1/6 F, (b) 1/8 F, and (c) 1 / 26 F. Note that the capacitance values ar
