Compute the maximum value of the voltage induced in the coil, Electrical Engineering

Assignment Help:

Q. The coil is placed so that its axis of revolution is perpendicular to a uniform field, as shown in Figure If the flux per pole is 0.02 Wb, and the coil, consisting of 2 turns, is revolving at 1800 r/min, compute the maximum value of the voltage induced in the coil.

2418_Compute the maximum value of the voltage induced in the coil.png
