Left side view of a motorcycle parts of motorcycle, Mechanical Engineering

Assignment Help:

1370_right side.png

Figure : Left Side View of a Motorcycle

Part No.

Name

Functions

1

Fuel cock

Used to open or close the fuel supply

2

Engine guard

For the safety of engine

3

Gear shift pedal

Used to change the gears

4

Air suction valve

Used to supply air to exhaust manifold

5

Rider foot rest

Foot rest for rider/driver

6

Main stand

Used to mount the bike in vertical position

7

Left Side cover

Cover the body parts

8

Side stand

Used to mount the bike in a tilted position

9

Pillion foot rest

For the foot rest of pillion

10

Sari guard

Guard to protect sari from coming into wheel

11

Seat cum helmet lock

To lock seat and helmet

12

Rear grip

Support and grip for pillion rider
